Malta Dynamics A7361 Weld-On Puck for 5K Swivel Anchor | Canada
Malta Dynamics A7361 Weld-On Puck, steel base for 5K swivel anchors. An uncoated mild steel base that is welded directly to structural steel, giving a Malta Dynamics 5K swivel anchor a permanent or semi-permanent mounting point where drilling is not an option. A Class 8.8 M12 bolt and internal tooth lock washer are included.
Malta Dynamics A7361 weld-on puck key features
- Welds directly to structural steel beams for a permanent or temporary installation
- Rated to a 5,000 lb minimum breaking strength
- Uncoated mild steel, ready for welding and for jobsite-specific coating or finishing
- Class 8.8 M12 bolt and internal tooth lock washer included
- Works with Malta Dynamics 5K swivel anchors #A7360 and #A7360C
- Low-profile anchor point with no through-bolting needed
Malta Dynamics A7361 weld-on puck specifications
| Manufacturer | Malta Dynamics |
|---|---|
| Model / SKU | A7361 |
| Minimum breaking strength | 5,000 lb |
| Material | Uncoated mild steel |
| Hardware included | Class 8.8 M12 bolt, internal tooth lock washer |
| Compatible anchors | Malta Dynamics 5K swivel anchors A7360 and A7360C |
| Installation | Welded to structural steel |
| Standards | ANSI Z359.18-2017, OSHA |
| Weight / dimensions | Not published by Malta Dynamics; ask us |
When to use the Malta Dynamics A7361 weld-on puck
Steel-frame buildings
Weld a fixed anchor base to a beam where drilling is not allowed.
Custom fall protection systems
Build anchor points into fabricated steel structures.
Plants and maintenance areas
Give a 5K swivel anchor a semi-permanent home on site steel.
Fabrication shops
Weld bases in the shop, then coat to suit the job.
Is the Malta Dynamics A7361 CSA certified? Compliance in Canada
Is the Malta Dynamics A7361 weld-on puck CSA certified?
No. Malta Dynamics rates it to OSHA and ANSI Z359.18-2017, not CSA. For CSA-marked anchors see our Safety Direct range.
Which anchors fit the Malta Dynamics A7361 weld-on puck?
Malta Dynamics lists its 5K swivel anchors, #A7360 and #A7360C.
Does the Malta Dynamics A7361 come with a bolt and washer?
Yes. It comes with a Class 8.8 M12 bolt and an internal tooth lock washer.
Why is the Malta Dynamics A7361 puck left uncoated?
It is uncoated mild steel so it is ready to weld; coat or finish it to suit your site after welding.
Pair the Malta Dynamics A7361 with a 5K swivel anchor
The A7361 is the base only. Add a Malta Dynamics 5K swivel anchor, then an SRL or lanyard and a full-body harness. Welding and the anchorage should be designed and checked by a qualified person.
