Safety Direct Anchorage Connector
Safety Direct Anchorage Connector
A precision-machined bolt-through anchorage connector designed for permanent installation on structural steel beams and concrete surfaces. Available in three hole sizes to match standard bolt diameters, this connector provides a certified tie-off point for fall arrest, positioning, and travel restraint systems on Canadian construction and industrial worksites.
Key Features
- Bolt-through design for permanent anchorage on structural steel and concrete
- Available in 1/2", 5/8", and 3/4" hole sizes to match standard bolt diameters
- Precision-machined from high-strength steel for reliable fall arrest anchorage
- Single D-ring connection point for fall arrest, positioning, or travel restraint
- Compact profile minimizes obstruction on beams and structural members
- Rated to 5,000 lbs (22.2 kN) for single-person fall arrest
- CSA Z259.15 compliant anchorage connector for Canadian worksites
| Specifications | |
|---|---|
| Type | Bolt-Through Anchorage Connector |
| Material | High-Strength Steel |
| Hole Sizes | 1/2", 5/8", 3/4" |
| Connection | Single D-Ring |
| Rated Capacity | 5,000 lbs (22.2 kN) |
| CSA Standard | Z259.15 — Anchorage Connectors |
| Manufacturer | Safety Direct (Canada) |
| SKU | Hole Size | MSRP |
|---|---|---|
| RP3732-1 | 1/2" | $55.05 |
| RP3732-2 | 5/8" | $55.05 |
| RP3732-3 | 3/4" | $55.05 |
CSA Z259.15 Compliant
All Safety Direct Anchorage Connectors meet CSA Z259.15 — the Canadian standard for anchorage connectors used in fall protection systems. Required on all Canadian construction and industrial worksites where fall arrest anchorage is mandated by provincial OHS regulations including Ontario O. Reg. 213/91, Alberta OHS Code Part 9, and BC OHS Regulation Part 11.
Permanent Structural Anchorage You Can Trust
Not sure which hole size fits your application? Contact us for expert guidance on CSA-compliant anchorage connectors.
All prices in CAD. Pricing subject to change.
